Introducing the CTC-7 Cold & Heat Compression System, the lightest & most transportable All in one therapy device.
- The CTC-7 Simultaneously delivers hot & cold therapy with active air compression
- Active Air compression helps to reduce swelling & stimulate blood flow
- No Ice needed
- Cold & heat compression
- Selectable wraps
- Easy Maintenance
- Auto Water Check
HOW TO INSTALL:
- Carefully open the package to avoid damaging the product. Make sure the device, tubing, and garment are in good condition and not damaged before use.
- Place the device on a flat, stable surface. Leave at least 30 cm of space around the device to ensure proper air flow.
- Open the water bottle cap at the back of the device. Fill the bottle with distilled water and screw the cap back on tightly.
- Use a jug with a sharp spout to pour the water.
- Check the water level indicator at the back of the device.
- The maximum distilled water capacity is 250 mL. The device will need more water as it operates and the initial water moves to the garment.
- Locate the water socket on the side of the device. Connect the garment water tubing to this socket until you hear a “click.”
- Make sure the tubing is properly connected to prevent water leaks.
- After connecting the water tubing, connect the air tubing to the air socket by pushing it until you hear a “click.”
- Check if the pipe attached to the reusable wrap is twisted. (Disposable wraps do not have drain pipes.)
- If the pipe is twisted 90 degrees, distilled water may spill.
- Locate the power cord socket on the side of the device. Plug in the power cord and connect the device to a power outlet.
- Make sure the device is in a location where the power cord can be easily plugged in and unplugged.
HOW TO USE:
- Turn on the power switch on the side of the device to display the mode selection screen.
- On the mode selection screen, turn the dial either counterclockwise or clockwise to choose your desired mode. Press the dial to confirm your selection. The screen will then show the settings for the chosen mode.
- After selecting the mode, press the start/stop button to begin. (Press the button with your thumb, covering it completely, but there’s no need to press hard.)
- While the device is running, you cannot change the settings.
- To adjust the settings, stop the device by pressing the start/stop button.
- You can pause the therapy by pressing the dial, but you cannot change the settings while it is paused.
